Fire Science: Wildfire Monitoring and Prediction


Fire Imaging

Baker Fire, Kern County, CA
12 September 2011 between 13:12 and 14:04 PDT


As viewed by the FireMapper™ Thermal-Imaging Radiometer


Click on the image above to view a larger Zoomify image with pan and zoom
or view the JPEG version
(opens a new browser window)

Ground surface temperatures as viewed from above at 8-12 micrometers wavelength in the thermal infrared.



Image 1: Thermal Mosaic
Plan view of fire. Warmer tones (red, orange, yellow) represent recent or active combustion; areas of light gray are cooling ash or warm bare ground and the low temperatures of unburned forest and cool ground are shown in darker gray (see chart above).


Purple is used to show cooling ash but could be associated with bare ground away from fire.


Click on the image above to view a larger JPEG image
(opens a new browser window)







Weather conditions at time of data collection :
Tehachapi station TMNC1; data from NOAA ROMAN system.

Past Weather Conditions for Tehachapi
Most Recent Observations at September 11, 2011 - 11:53 PDT


11:53 24 Hour Max 24 Hour Min
Temperature 72.0° F 72.0 at 11:53 47.0 at 6:53
Dew Point 29.9° F 51.5 at 16:53 29.9 at 11:53
Relative Humidity 21% 97 at 4:53 21 at 11:53
Wind Speed 4 mph from SSE 6 at 12:53 0 at 19:53
Wind Gust 13 mph 15 at 10:53 1 at 21:53
Fuel Temperature 85.0° F 85.0 at 11:53 44.0 at 6:53
10 hr Fuel Moisture 11 gm 23 at 7:53 10 at 15:53
Battery voltage 13.70 volt 14.40 at 12:53 12.60 at 5:53

Archives of past fires: 2008 2007 2006 2005 2004 2003 2002 2001


Forest mapping: 2008 2007 2006 2005 2004 2003 2002 2001


FireMapper™ Specifications: Instrument

FireMapper™ References: Publications

FireMapper™ Tools- image analysis software: ftp downloads page

For Further Information: contact Dr. Philip J. Riggan



FireMapper™ has been developed through a Research Joint Venture with Space Instruments, Inc., and support from the National Fire Plan, Forest Service International Programs, the U.S. Department of Agriculture, the Joint Fire Sciences Program, and the U.S. Agency for International Development.
