Zaca Fire, Santa Barbara County, CA
20:26 PDT 28 August 2007
As viewed by the FireMapper Thermal-Imaging Radiometer
|
Click on the image above to view a larger Zoomify image
or view the JPEG version
(opens a new browser window)
NOTE: Flight covered all active firelines as shown on 8-24 fire perimeter map.
Current Image: Thermal mosaic
Ground surface temperatures as viewed from above at 11.9 micrometers wavelength on 28 August 2007, between 20:26 and 21:54 PDT.
|
|
|
Image 1: Thermal Mosaic
Plan view of fire. Warmer tones represent recent or active combustion; areas of light gray are cooling ash or warm bare ground and the low temperatures of unburned forest and cool ground are shown in darker gray (see chart above).
Purple is used to show cooling ash but could be associated with bare ground away from fire.
|
Click on the image above to view a larger JPEG image
(opens a new browser window) |
|
|
Image 2: Thermal Mosaic with hotspots highlighted
Plan view of fire. Warmer tones represent recent or active combustion; areas of cooling ash or warm bare ground and the low temperatures of unburned forest and cool ground have varying degrees of transparency.
Purple is used to show cooling ash but could be associated with bare ground away from fire.
|
Click on the image above to view a larger Zoomify image
or view the JPEG version
(opens a new browser window) |
|
|
Hotspots
|
|
|
|
Weather conditions at time of data collection :
from NOAA ROMAN system. |
Past Weather Conditions for LPOC1
Observations prior to selected time: August 28, 2007 - 22:00 PDT
Weather Conditions at August 28, 2007 - 21:14 PDT
|
21:14 |
24 Hour Max |
24 Hour Min |
Temperature |
76.0° F |
103.0 at 14:14 |
60.0 at 5:14 |
Dew Point |
49.9° F |
57.8 at 12:14 |
49.7 at 17:14 |
Relative Humidity |
40% |
70 at 4:14 |
20 at 14:14 |
Wind Speed |
0 mph |
5 at 17:14 |
0 at 22:14 |
Wind Gust |
6 mph |
14 at 13:14 |
0 at 22:14 |
Solar Radiation |
0.0 W/m*m |
822.0 at 13:14 |
0.0 at 22:14 |
Fuel Temperature |
76.0° F |
119.0 at 14:14 |
61.0 at 4:14 |
10 hr Fuel Moisture |
7 gm |
10 at 6:14 |
6 at 16:14 |
Battery voltage |
12.60 volt |
13.00 at 10:14 |
12.50 at 3:14 |
|
