Vegetation mortality
survey,
Crestline area at low altitude
27 May 2003
As viewed by the FireMapper
system
in reflected red, near-IR, and thermal IR frequencies
Images were collected
from the PSW Airborne Sciences Aircraft flying over the
area near Cedarpines Park.
|
|
|
Location Map:
Shaded relief map of the Silverwood Lake, Lake
Arrowhead, Keller Peak, North San Bernardino, Hamilton
Mountain area. Color overlays show area of processed
imagery.
|
Click on the image above to view a larger JPEG image in a new browser
window
|
|
|
Image 1:
Mosaic of images from flights over study plots near Cedarpines Park.
|
Click on the image above to view a larger JPEG image in a new browser
window at full resolution
|
|
Healthy vegetation is bright green; stressed or dying
vegetation is orange-brown in this false-color depiction.
|
|
(This RGB image shows reflected red light at 650 nm in
red, reflected NIR at 850 nm in green, and thermal IR at
10.5 um in blue.)
|
|
|
Image 1a:
Portion of above mosaic of images from flights over study plots near Cedarpines Park.
View this image as a Google Earth overlay
|
Click on the image above to view a larger JPEG image in a new browser window at full resolution
|
|
|
Image 1b:
Portion of mosaic of images from 2001 flight over study plots near Cedarpines Park. |
Click on the image above to view a larger JPEG image in a new browser window at full resolution
|
|
|
Image 2:
Image of area near Cedarpines Park. |
Click on the image above to view a larger JPEG image in a new browser window at full resolution
|
|
(This RGB image shows reflected red light at 650 nm in red, reflected NIR at 850 nm in green, and thermal IR at 10.5 um in blue.) |
|
|
Image 2a:
Image of area near Cedarpines Park. |
Click on the image above to view a larger JPEG image in a new browser window at full resolution
|
|
(This RGB image shows reflected red light at 650 nm in red, reflected NIR at 850 nm in green, and SWIR at 1.5 um in blue.) |
|
|
Image 3:
Image of area near Cedarpines Park. |
Click on the image above to view a larger JPEG image in a new browser window at full resolution
|
|
(This grayscale image shows thermal IR at 10.5 um in degrees C. The 50 degree C temperature range is displayed using 50 levels of gray.) |
|
|
Image 3a:
Image of area near Cedarpines Park. |
Click on the image above to view a larger JPEG image in a new browser window at full resolution
|
|
(This grayscale image shows thermal IR at 10.5 um in Digital Numbers. The 50 degree C temperature range is displayed using 256 levels of gray.) |
|
|
|
|
|
|
